Table Electronic Tensile Machine
Table Electronic Tensile Machine
This is a Table Electronic Tensile Machine attached with the micro printer, it can not only can test the tensile strength, compressive strength and extension length of all kinds of material, semi-finished products and products, but also do the testing of stripping, tearing, bending, flexural, compression etc. Therefore, it is widely applied in the field of metal, plastic, rubber, textile, synthetic chemicals, wire and cable, leather etc

Main Technical Parameters:
Max. Capacity (Optional):50N、100N、200N、500N、1000N
Test range of test force:0.4%~100 FS ( full range)
The indicated error of test force:≤ ±0.5%
The resolution of test force:±1/250000 of max. force, there is no grades in the whole process ,and the process keep the constant resolution
The valid length of tensile:800mm (clamp is not included)
The error of indicated displacement:≤ ±0.2% (indication)
The resolution of displacement: 0.015mm
The range of test speed:50~500 mm/min(adjustable)
External dimensions:55×45×135cm
Weight:75Kg
Power Supply:220V/50Hz
Power:120W
Ordering Information:
  BGD572--- Table Electronic Tensile Machine
